Question: When viscous dissipation is appreciable,
When viscous dissipation is appreciable, conservation of energy [Eq. (5.6)] must take into account the rate at which mechanical energy is irreversibly converted to thermal energy due to viscous effects in the fluid. This gives rise to an additional term, f, the viscous dissipation, on the right-hand side, where:
![When viscous dissipation is appreciable, conservation of energy [Eq. (5.6)] must take into account the rate at which mechanical energy is irreversibly converted to thermal energy due to viscous effects in the fluid. This gives rise to an additional term, f, the viscous dissipation, on the right-hand side, where:
Apply the resulting equation to laminar flow between two infinite parallel plates, with the upper plate moving at a velocity U. Assuming constant physical properties (r, cp, k, and m), obtain expressions for the velocity and temperature distributions. Compare the solution with the dissipation term included with the results when dissipation is neglected. Find the plate velocity required to produce a 1-K temperature rise in nominally 40°C air relative to the case where dissipation is neglected.](../images/when-viscous-dissipation-is-appreciable-conservation-of-energy-eq--278536-1.jpg)
Apply the resulting equation to laminar flow between two infinite parallel plates, with the upper plate moving at a velocity U. Assuming constant physical properties (r, cp, k, and m), obtain expressions for the velocity and temperature distributions. Compare the solution with the dissipation term included with the results when dissipation is neglected. Find the plate velocity required to produce a 1-K temperature rise in nominally 40°C air relative to the case where dissipation is neglected.
